Computing System
-
Processor
Intel Core i3-N300 processor (8-core, 0.8 GHz, up to 3.8 GHz)
-
Chipset
Intel
-
System Memory
8GB LPDDR5 onboard memory
Graphics
-
Graphics Engine
Intel UHD Graphics (Integrated)
-
Video Output
HDMI 2.0 (up to 3840×2160@60Hz)
DisplayPort 1.4 (up to 4096×2160@60Hz)
DP1.4 via USB-C (3840×2160 @ 60Hz)
Triple Display Ready
Storage
-
Hard Drive
N/A
-
Mass Storage
N/A
-
Optical Drive
N/A
-
mSATA
N/A
-
M.2
1 x M.2 NVMe PCIe 3.0 x4 / SATA SSD slot (2230, 2242, 2280)
-
Card Reader
Micro SDHC/SDXC
I/O Ports
-
Audio
1 x Headphone/microphone combo jack
-
USB Port
3 x USB 3.2 (1 Type-C)
-
LAN
10/100/1000 Ethernet
-
Antenna
Internal
-
Wifi
WiFi 6
-
Bluetooth
Bluetooth 5.2
-
Legacy I/O
N/A
-
CIR Infrared Port
N/A
-
Thunderbolt
N/A
-
USB
N/A
-
IDE
N/A
-
VGA
N/A
Mechanical
-
Kensington Lock
N/A
-
LED Indicators
N/A
-
Power Supply
AC Adapter
O/P: DC 5V/5A -
Cooling system
Solid State Active Cooling
-
ZBOX Dimensions
114.8mm x 76mm x 23.8mm (4.52in x 2.99in x 0.94in)
-
Case Mounting
Mounting Bracket
Miscellaneous
-
Supported OS
Windows 11 Ready
-
Accessories
Universal Power Adapter with Multiple Plugs
Mounting bracket
2 x Mount screws
CTIA / OMTP adapter
Warranty Card
Quick Install Guide
USB drive with drivers
