TP-LINK Tapo C545D WiFi kamera

Leírás

CAMERA

Image Sensor 1/2.8“ Progressive Scan CMOS Sensor
Lens Focal Length: 6 mm ± 5%, 2.53 mm±5%
Aperture: F1.6 ± 10%, F1.6 ± 10%
Field of View: 66.5° (Diagonal), 57.3° (Horizontal), 31.7° (Vertical);
165.1° (Diagonal), 137.6° (Horizontal), 73.0° (Vertical)
Night Vision 850 nm IR LED (99 ft / 29.9 m), Color Night Vision
Day/Night Switch IR-Cut Filter with Auto-Switching
Interface & Button 1× RJ45 (10M/100M) Ethernet Port
1× RESET Button
1× microSD Card Slot (Up to 512 GB)
VIDEO & AUDIO

Maximum Resolution 2K 3MP (2304 x 1296 px) + 2K 3MP (2304 x 1296 px)
Frame Rate 15 fps
Video Compression H.264
Live View Yes
Image Enhancement 3DNR
WDR
Audio Input & Output Built-in Microphone and Speaker
Audio Communication Two-Way Audio with Noise Cancellation
Siren Volume 99 dB (Level measured at 4-inch/10-cm distance)
STORAGE

Local Storage microSD Card Slot on Camera (Up to 512 GB)
Cloud Storage Tapo Care Cloud Storage Services (Subscription required)
DETECTION and NOTIFICATIONS

AI Detection Motion Detection
Person Detection
Pet Detection
Vehicle Detection
Line-Crossing Detection
Camera Tampering
Activity Zones Yes
*Only works with Motion/Person/Pet/Vehicle Detection.
Output Notification System Notification
System Notification with Snapshot (Tapo Care Services)
NETWORK

Network Connectivity Connect via Wi-Fi or Ethernet
Wireless Connectivity IEEE 802.11 b/g/n/ax, 2.4 GHz
Protocol TCP/IP, DHCP, ICMP, DNS, NTP, HTTPS, TCP, UDP
Ethernet Port Yes
RTSP Yes
ONVIF Yes
Transmission Rate 11b: 11 Mbps
11g: 54 Mbps
11n: 72.2 Mbps
11ax: 143.4 Mbps
SECURITY

Security On-Device Machine Learning
128-bit AES Encryption with SSL/TLS
WPA/WPA2-PSK/WPA3
POWER

Power Source 12 V DC Power Adapter
Input Voltage 100-240 V, 50/60 Hz
Output Voltage 12 V, 1 A (DC Power)
DC Power Connector Size Inside O: 2.1 mm
Outside O: 5.5 mm
Power Cord Length 3 m
Typical Power Consumption 5.3 W
Maximum Power Consumption 11.2 W
GENERAL

Smart Integration Google Assistant, Amazon Alexa, Samsung SmartThings
Weather Resistance IP66
Mounting Options Wall-Mounted
Eave-Mounted
Pole-Mounted
Operating Temperature -30 oC ~ 60 oC (-22 °F ~ 140 °F )
Storage Temperature -40 oC ~ 60 oC (-40 °F ~ 140 °F)
Operating Humidity 10% ~ 90% RH, Non-condensing
Storage Humidity 0 ~ 90% RH, Non-condensing
Dimensions ( W x D x H ) 4.51 × 6.28 × 5.99 in (114.57 × 159.55 × 152.1 mm)
Weight 17.32 oz / 491 g
Package Content Tapo C545D Camera ×1
Mounting Bracket ×1
Mounting Template Sticker ×1
Mounting Screws ×4
Mounting Anchors ×4
Waterproof Seal ×1
Waterproof Cable Attachments ×1
Power Adapter ×1
Quick Start Guide
